V - Series Skid Steer Tree Shear For commercial and farm operations
• Shear blades are heavy duty, specially developed and angled for best cutting performance. The blades are carried on heavy duty steel bars for extra strength. Blades can be sharpened as needed with a hand grinder.
• Brush guard is standard equipment.
SPECIFICATIONS:
Model SS-3
Model
SS-4
Model
SS-5
Model SS-6
Main
Frame:
¼"
Steel Plate
3/8"
Steel Plate
3/8"
Steel Plate
3/8"
Steel Plate
Blades:
1/2"
x 6"
3/4" x 8"
1" x 10"
1"
x 12"
Weight:
760 lbs.
1040 lbs.
1500 lbs.
1750 lbs.
Cylinder
3" Dia. x
6" Stroke
4" Dia. x 6" Stroke
5" Dia. x 8" Stroke
5" Dia. x
8" Stroke
Cylinder
Rods:
1
1/2"
Diameter
2"
Diameter
2"
Diameter
2"
Diameter
Shear
Capacity:
7"
Diameter
10"
Diameter
12"
Diameter
16"
Diameter
Options
Available:
Stump Sprayer
Nozzle
NOTES:
Tractor
Hydraulic Pressure- 2000 to 3000 psi, 12 to 18 gpm Hydraulic Fluid
Comes
complete with hoses from tee to cylinders, cylinders, and mounting pins.
DOES NOT include hoses from the tractor unit to the tree shear.
